Jazzy Air 2.0 Key Features
Under seat storage
VFront compartment keeps your valuables accessible.
Fast Rise
12” of power adjustable seat height in 11 seconds.
Mid-wheel 6® with Active-Trac® Suspension
Enhanced performance and maximum stability both indoors and out.
Bright LED Lighting
Visibility in all environments.
Elevate your life to the next level!
At the touch of a switch, the Jazzy Air® 2 elevates 12” in just 11 seconds. With a sleek, more modern look, this power chair safely drives at speeds up to 4 mph while elevated, allowing users to enjoy face-to-face social engagement. With Mid-Wheel 6® Drive and Active-Trac® Suspension, the Jazzy Air® 2 offers enhanced performance and stability both indoors and out.
FEATURES:
- High-back or solid seat pan, reclining sport seat. Seat features 2” of depth adjustment. Choice of 16”x16”-18”, 18”x18”-20”, 20”x20”-22”
- Angle, height and depth adjustable armrests
- Height adjustable headrest
- Newly re-designed lift features:
- 2” lower seat-to-floor height enables user to sit comfortably at standard table or desk
- Raises and lowers in 11 seconds by using the Air switch or VR2 joystick
- Additional features:
- Drives safely at 4 mph in the elevated position
- Integrated foot platform with rubber insert and 2”of adjustment for comfort in both the elevated and non-elevated positions
- Bright LED marker lights offers visibility in all environments
- Active-Trac® suspension with Mid-Wheel 6® Technology allows for maximum stability in the elevated and non-elevated positions
- Single-sided caster forks for enhanced maneuverability
- Under seat front storage compartment keeps your valuables accessible
SPECIFICATIONS:
| Model |
Jazzy Air® 2
|
| Weight Capacity | 300 lbs. |
| Turning Radius1 | 20.75″ |
| Width1 | 23.19″ |
| Length1,2 | 41.93″ |
| Maximum Speed3 | Up to 4.0 mph (elevated and non-elevated position) |
| Ground Clearance1 | 1″ at motor bracket |
| Front Wheels | 6″ flat free |
| Drive Wheels | 10″ flat free |
| Rear Wheels | 6″ flat free |
| Drivetrain | Two motor, Mid-Wheel 6® drive |
| Braking System | “Intelligent Braking” (electronic regenerative, disc park brake) |
| Suspension Type | Active-Trac® with Mid-Wheel 6® Technology |
| High-Back Seat (max. size) | 20″W x 20″-22″D |
| High-Back Seat-to-Floor Range | 21.25” – 33” |
| Battery Size (2 required) | 12 volt, U-1 Optional 40 Ah |
| Battery Weight5 | U1 Batteries: 24.5 lbs. 40 Ah Batteries: 32.5 lbs. |
| Standard Battery Charger | 5 amp, off-board |
| Per-Charge Range3,6 | Up to 16.8 miles (U1) Up to 19.2 miles (40 Ah) |
| Warranty
All orders come with a manufacturer warranty -labour is excluded |
|
|---|---|
| Warranty | 5-year limited on frame; 13-month limited on electronics; 13-month on drive motors; 13-month limited on batteries. |
